Blue Sea Panel Wd 12 Vdc Fused 8 Pos Gray

Blue Sea Panel Wd 12 Vdc Fused 8 Pos Gray

R5325,00 incl.

  • Panel front rated IP67 when properly mounted with watertight mounting gasket
  • IP67 – protected against immersion up to 1 meter for 30 minutes
  • Designed for flybridge and open cockpit applications
  • Independent label backlighting circuit for remote switching and dimming
  • Available in 2, 4, 6, and 8 circuit models
  • Each panel can be mounted in four different orientations
  • Integrated ATO/ATC fuse based circuit protection
  • Bicolored LEDs illuminate circuit labels to quickly identify OFF (Red), ON (Green), or Blown (No Color) circuits. No lights in any position likely indicate there is no power to the panel.

1 in stock

SKU: PO-BS4308 Category: Tag:

Description



Specifications
Weatherproof Waterproof
Positions 8
Nominal Voltage 12V DC
Circuit Protection Fuse
Maximum Amperage 15A @ 12V DC (per circuit)
Panel Cumulative Rating 100A
Backlit Label Bicolored LED
Backlighting Amperage 10mA /Illuminated Circuit
Backlighting Voltage 12V DC
Material Reinforced Polycarbonate
Height 7.70in (195.58 mm)
Width 3.88in (98.55 mm)
Depth 2.50in (63.5 mm)
Weight 1.55lb (0.7 kg)

Additional information

Weight 0,7 kg
Dimensions 19 × 9 × 6 cm
